Model 24
24-TRACK LIVE RECORDER & MIXING CONSOLE WITH AUDIO INTERFACE
TASCAM has been continuously providing industry-leading recording solutions for decades, such as the TASCAM 38 Open Reel 8-track, the DA-88 Digital 8-track and the legendary Portastudio Cassette and Digital Multitrack recorders. TASCAM now builds on this legacy to deliver a new classic: the Model 24 Multitrack Recorder/Mixer/Interface.
Whether used for rehearsal, live shows or studio production, this triple-function recording console perfectly meets the needs of today’s working and recording musician
- Supported Media : SD (512MB to 2GB), SDHC (4GB to 32GB), SDXC (64GB to 512GB) Class 10 or higher required.
- Maximum Recordable ChannelNumber : Max. 24 channels (22ch + 2 stereo mix)
- USB Audio
Maximum INPUT : 24ch
Maximum OUTPUT : 22ch - Bluetooth®
Output Class : Class 2 (Transmission range: approx. 33 ft. / 10 m)
Version : 4 - Dimensions : 576 × 112.5 mm × 513 (including side panels, knobs and connectors)
- Weight : 22.49 lbs. / 10.2 kg
- All-in-One, Multitrack Recorder with 22 channel Mixer and USB Audio Interface
- WAV 48kHz/24-bit, 24 channel multitrack recording to SD, SDHC and SDXC cards
- 22 Inputs (20 Balanced, 12 Monaural, and 4 Stereo)
- 16 TASCAM Microphone Preamps
- 3-band EQ with a sweepable mid-range frequency (Channels 1 to 12)
- 100kHz Low-cut Filter (Channels 1 to 12)
- 7-band Graphic EQ
- 16 Pre-set Effects
- Model 24 x 1
- AC adaptor (TASCAM PS-M1524A) x 1
- Cord for AC adapter (JAPAN USA/EUROPE/AUSTRALIA) x 3
- Owner’s Manual (this document) including warranty x 1
Simple, Intuitive Design
One glance is all you need. The TASCAM Model 24 was developed for easy operation, with everything you need placed right at your fingertips. 100mm faders allow for precise control over volume. A full set of familiar EQ and Auxiliary knobs remove the need for menu diving, and all input/output connections are on the surface for quick and easy access.
The Model 24 is truly a modern take on a classic design.
TASCAM’s Revolutionary Recording Technology
Featuring 16 high-grade TASCAM mic preamps in addition to multiple sets of stereo line inputs, the Model 24 delivers studio quality audio performance right from the start. When it’s time to record the TASCAM Model 24 allows musicians and engineers to capture up to 24 tracks simultaneously (at 24bit/48kHz resolution) directly to the SD card, with the ability to punch in/out eight tracks at the same time. And once the take is done, the Model 24 can easily playback any or all of the recorded tracks through the console for mixdown.
Flexible Connectivity
In addition to the studio quality mic preamps and powerful EQ and routing options, the Model 24 features a dedicated stereo channel 1/8”, dual RCA and Bluetooth™ connectivity. This allows users to easily integrate mobiles devices into the mix for rehearsal playback, walk-in music and more. Finally, the TASCAM Model 24 can also act as a powerful audio interface, and connects directly to your PC or Mac for easy integration with your DAW of choice.
Durability and Reliability
Designed to be both lightweight and rugged, the Model 24 can easily be carried from studio to stage with the confidence that TASCAM’s legendary reliability will keep the music going.
Additional Features
A true triple threat
Read More
Record
Read More
Connect
Read More
Mix
Read More
Channel surfing
Read More
Master and Commander
Read More
Make Tracks
Read More
Live and Let DAW
Read More
Features at a Glance
- All-in-One, Multitrack Recorder with 22 channel Mixer and USB Audio Interface
- WAV 48kHz/24-bit, 24 channel multitrack recording to SD, SDHC and SDXC cards
- 22 Inputs (20 Balanced, 12 Monaural, and 4 Stereo)
- 16 TASCAM Microphone Preamps
- 3-band EQ with a sweepable mid-range frequency (Channels 1 to 12)
- 100kHz Low-cut Filter (Channels 1 to 12)
- 7-band Graphic EQ
- 16 Pre-set Effects
- 100mm Long-throw Faders for precise adjustment
- Mute, Main/Sub, PLF switches on every input channel
- Bluetooth® input supporting both AAC and SBC codecs
- SUB Outputs via XLR Balanced and RCA Unbalanced connectors
- LINE Inputs via RCA Pin and 1/8" Stereo Mini jacks
- 3 AUX Outputs (Monitor 1, Monitor 2, FX)
- 1 Stereo Output for Control Room
[Updated] Information on the connectivity of TASCAM products with iPhone/iPad USB-C port
Learn More
[Updated] Information regarding Windows 11 Version 24H2 compatibility
Learn MoreYou might also like
Spec description
| Recording section | |
| Supported Media | SD (512MB to 2GB), SDHC (4GB to 32GB), SDXC (64GB to 512GB), Class 10 or higher required. |
| File System | SD card: FAT16, SDHC card: FAT32, SDXC card: exFAT |
| Recording File Format | WAV(BWF) |
| Playback Format | WAV(BWF) |
| Sampling Frequency | 44.1k / 48k Hz |
| Bit Depth | 16 / 24 bit |
| Recordable Channel | Max. 24 channels (22ch + 2 stereo mix) |
| Audio Inputs | |
| MIC IN | CH1 to 12, 13/14 to 19/20 |
| Connector | XLR 3-31 (1: GND, 2: HOT, 3: COLD) |
| Maximum Input Level | +10dBu |
| Nominal Input Level | –8dBu |
| Minimum Input Level | –58dBu |
| Gain Adjustable Range | 0 to 50dB |
| Input Impedance | 1.8kohm |
| Phantom Power supply | +48V |
| LINE IN | CH1 to 20 |
| Connector | 1/4" (6.3mm) TRS Phone jack (Balanced) |
| Maximum Input Level | +22dBu |
| Nominal Input Level | +4dBu |
| Gain Adjustable Range | –10 to +40dB: CH1 to 12, +20 to +30dB: CH13/14 to 19/20 |
| Input Impedance | 22kohm |
| INSERT | CH 1 and 2 |
| Connector | 1/4" (6.3mm) TRS Phone jack (T: Send, R: Return, S: GND) |
| Return (Ring) | |
| Maximum Input Level | +18dBu |
| Nominal Input Level | 0dBu |
| Input Impedance | 10kohm |
| Send (Tip) | |
| Maximum Output Level | +18dBu |
| Nominal Output Level | 0dBu |
| Output Impedance | 100ohm |
| RCA INPUT | |
| Connector | RCA Pin jack (Unbalanced) |
| Maximum Input Level | +8dBV |
| Nominal Input Level | –10dBV |
| Input Impedance | 10kohm |
| STEREO INPUT | |
| Connector | 1/8" (3.5mm) Stereo Mini jack (Unbalanced) |
| Maximum Input Level | +8dBV |
| Nominal Input Level | –10dBV |
| Input Impedance | 10kohm |
| OUTPUTS | |
| MAIN OUTPUT | |
| Connector> | XLR 3-32 (1: GND, 2: HOT, 3: COLD) |
| Maximum Output Level | +22dBu |
| Nominal Output Level | +4dBu |
| Output Impedance | 100ohm |
| SUB OUT, MONITOR, FX OUT, CONTROL ROOM OUT | |
| Connector> | 1/4" (6.3mm) TRS Phone jack (T: HOT, R: COLD, S: GND) |
| Maximum Output Level | +16dBu |
| Nominal Output Level | -2dBu |
| Output Impedance | 100ohm |
| PHONES OUT | |
| Connector | 1/4" (6.3mm) Stereo Phone jack |
| Output Level | 80mW + 80mW (32 ohm loaded) |
| Working impedance | 16 to 600 ohm |
| REMOTE | Compatible with TASCAM RC-1F Foot Switch |
| Connector | 1/4" (6.3mm) TS Phone jack |
| USB | |
| Connector | USB B type 4-pin |
| Transfer Format | USB2.0 High-Speed |
| Format | Mass-storage class/USB Audio Class 2.0 (USB class-compliant) |
| USB Audio | |
| Sampling Rate | 44.1k / 48k Hz |
| Bit Depth | 16 / 24 bit |
| INPUT | 24ch *Output from this unit |
| OUTPUT | 22ch *Input to this unit |
| Bluetooth® | |
| Output Class | Class 2 (Transmission range: approx. 33ft. / 10 m) * Transmission range may vary, depending on surroundings. |
| Bluetooth® version | 4.0 |
| Supported Profile | A2DP, AVRCP 1.0 |
| Supported A2DP Codecs | SBC, AAC |
| A2DP Content Protection | SCMS-T |
| Channel EQ | |
| Low-Cut | 100Hz, –18dB / Octave |
| Hi-Shelving | +15dB / –15dB, Cut off frequency: 12kHz |
| Mid | Peaking (MONO): +15dB / –15dB, 100Hz to 8kHz Variable (STEREO): +15dB / –15dB, Center frequency = 600Hz MID Band Q Fix, 0.55 |
| Low-Shelving | +15dB / –15dB, Cut off frequency = 80Hz |
| Graphic EQ | |
| Band | 7-Band |
| Frequency | 125 / 250 / 500 / 1k / 2k / 4k / 8k Hz |
| Gain | +15dB / –15dB |
| FX | |
| Type | 1: SMALL HALL / 2: LARGE HALL / 3: SMALL ROOM / 4: LARGE ROOM / 5: PLATE / 6: STUDIO / 7: LIVE / 8: SHORT DELAY/ 9: DELAY / 10: PING PONG / 11: CHORUS / 12: FLANGER / 13: DELAY + S.HALL / 14: DELAY + L.HALL / 15: CHORUS + S.HALL / 16: CHORUS + L.HALL |
| Power | AC 100 to 240V, 50/60Hz |
| Power Consumption | 52 W |
| Dimensions (W×H×D) | 576 × 112.5 mm × 513 (including side panels, knobs and connectors) 540 × 112.5 mm × 503 (excluding side panels. including knobs and connectors) |
| including Side panels | 22.67" × 4.43" × 20.20" / 576 × 112.5 mm × 513 (including knobs and connectors) |
| excluding Side panels) | 20.26" 4.43" × 19.80" × / 540 × 112.5 mm × 503 (including knobs and connectors) |
| Weight | 22.49 lbs. / 10.2 kg |
| Operating Temperature | 41˚ to 95˚F / 5˚ to 35˚C |
| Included Items | AC Cord, Owner's manual (incl. Warranty card), TASCAM ID registration guide |
| Available Accessories | TASCAM RC-1F Footswitch |
NOTE: 0dBV = 1Vrms, 0dBu = 0.775Vrms
Audio Performance
| Residual Output Noise | –100dBu (MAIN OUT, MAIN fader: MIN) |
| Equivalent Input Noise | –128dBu (Mono Input Channel, Rs: 150ohm, GAIN knob: Max) |
| Total Harmonic Distortion | 0.01% or less (MIC IN to MAIN OUT, Max input level, 1kHz, GAIN min.) 0.004% or less (MIC IN to MAIN OUT, +4dBu, 1kHz, GAIN min.) |
| Frequency Response | 20Hz to 30kHz (+0.5/–1.0dB: Analog) 20Hz to 20kHz (+0.5/–1.0dB: Digital) |
| Crosstalk | –80dB, channels/input and output (1kHz, PAN fully counter clockwise/fully clockwise) |
| Maximum Gain | 74dB (MIC to MAIN OUT) 50dB (MIC to INSERT OUT) 74dB (MIC to SUB OUT) 79dB (MIC to CR OUT) 75dB (MIC to MONITOR OUT) 75dB (MIC to FX OUT) 24dB (USB/SD to MAIN OUT) (EQ and-EQ flatten, PAN fully counter clockwise/fully clockwise) |
NOTE: 0dBu = 0.775Vrms
Supported PC
Windows
| Compatible Computers | Windows-compatible computer with a USB2.0 port |
| CPU | Dual core / 2GHz or faster |
| Memory | 2GB or more |
| Driver | USB Audio Class 2.0,  ASIO2.0, WDM (MME) |
| Screen Resolution | 1280 × 800 Dots or more |
Mac
| Compatible Computers | Apple Mac computer with a USB2.0 port |
| CPU | Dual core / 2GHz or faster |
| Memory | 2GB or more |
| Driver | Core Audio |
| Screen Resolution | 1280 × 800 Dots or more |
* Verified with Intel and Apple Silicon (M1 and M2) hardware
Supported OS' (PC)
Windows
Windows 11 2024 Update (Version 24H2) New , Windows 11 2023 Update (Version 23H2) , Windows 10 2022 Update (Version 22H2) , Windows 11 2022 Update (Version 22H2) , Windows 11 (Version 21H2) , Windows 10 (November 2021 Update) , Windows 10 (May 2021 Update) , Windows 10 (October 2020 Update) , Windows 10 (May 2020 Update) , Windows 8.1 , Windows 7Mac
macOS Sequoia , macOS Sonoma , macOS Ventura , macOS Monterey , macOS Big Sur , macOS Catalina , macOS Mojave , macOS High Sierra (10.13) , macOS Sierra (10.12) , OS X El Capitan (10.11)iOS
iOS 18 , iPadOS 18 , iPadOS 17 , iOS 17 , iOS 16 , iPadOS 16 , iOS 15 , iPadOS 15 , iPadOS 14 , iOS 14 , iPadOS 13 , iOS 13Information
| Latest version info | |
| Firmware | V1.63 |
| TASCAM Model Mixer settings panel (Windows) | V1.20 |
| TASCAM Model Mixer settings panel (macOS) | V1.20 |
- In firmware V1.62, if USB audio mode: STEREO MIX was selected, output would not be sent correctly to the computer. This has been fixed.
- When unit settings were initialized, if USB AUDIO was set to STEREO MIX, that setting was retained. This has been fixed.
- Operation stability has been improved.
- Commonalize of Model series (Model 24, Model 16, Model 12) software.
Notices About Products
Spec
Manuals
Documents
Firmware
Software
Supported Media / Other
Catalogs
The Model 12 is the only unit that has the DAW Control function. This is because the unit is built around a DIGITAL mixer. The earlier Model 24 and Model 16 are built around ANALOG mixers so they cannot have this function.
Only notarized applications can now be installed on Mac OS Catalina.
Please download again the application installer from the download tab on the respective product page and try installing it again.
